Geocell price high quality custom lane stabilization system is designed to improve the bearing capacity and long-term stability of lane foundation. With its honeycomb three-dimensional structure, it enhances the bearing capacity of foundation, prevents soil erosion, improves road stability, facilitates construction, and has environmental protection and energy-saving effects.
You need to communicate with suppliers according to your needs, get specific quotations, and choose reputable manufacturers to ensure quality and after-sales service. If you have specific project requirements, you can contact us to get a more suitable price plan.
| Cell Height | 50mm、75mm、100mm、150mm、200mm |
|---|---|
| Material Thickness | 1.0mm-2.0mm |
| Weld Spacing | 330mm、356mm、400mm |
| Expanded Cell Area | 10㎡-25㎡ |
| Cell Aperture Size | 200mm × 200mm-500mm × 500mm |
| Tensile Strength | 5 MPa-15 MPa |
| Elongation at Break | 10% -30% |
Geocell price High Quality Geosynthetics products are three-dimensional honeycomb structures made of high-density polyethylene (HDPE), polypropylene (PP) or other polymer materials. These cells form a series of interconnected pockets that can be filled with soil, gravel or concrete to form a strong and stable ground reinforcement system. Textured surface refers to the modification of the surface of the geocell, which increases the friction between the geocell and the fill material.
| Product | Cell Depth | Expanded Cell Size (W×L) mm | Expanded Panel Size (W×L) m | Expanded Panel Area | Weld length |
| (h) mm | m2 | (a) m | |||
| GG0735 | 75 | 259 X 224 | 2.56 X 6.52 | 16.7 ±1% | 356 |
| GG0744 | 75 | 320 X 287 | 2.56 X 8.35 | 21.4±1% | 445 |
| GG0771 | 75 | 508 X 475 | 2.56 X 13.72 | 35.12 ±1% | 711 |
| GG1035 | 100 | 259 X 224 | 2.56 X 6.52 | 16.7 ±1% | 356 |
| GG1044 | 100 | 320 X 287 | 2.56 X 8.35 | 21.4±1% | 445 |
| GG1071 | 100 | 508 X 475 | 2.56 X 13.72 | 35.12 ±1% | 711 |
| GG1535 | 150 | 259 X 224 | 2.56 X 6.52 | 16.7 ±1% | 356 |
| GG1544 | 150 | 320 X 287 | 2.56 X 8.35 | 21.4±1% | 445 |
| GG1571 | 150 | 508 X 475 | 2.56 X 13.72 | 35.12 ±1% | 711 |
| GG2035 | 200 | 259 X 224 | 2.56 X 6.52 | 16.7 ±1% | 356 |
| GG2044 | 200 | 320 X 287 | 2.56 X 8.35 | 21.4±1% | 445 |
| GG2071 | 200 | 508 X 475 | 2.56 X 13.72 | 35.12 ±1% | 711 |
1.Textured Surface: The surface of the cell is embossed or textured to improve friction and adhesion with the fill material, providing more effective stabilization.
2.High Strength and Durability: Textured geocells are made of HDPE or PP and can withstand harsh environmental conditions, including UV radiation, chemicals, and extreme weather.
3.Flexibility: They can adapt to different terrains and can be used in a variety of applications, including slopes, roads, and landfills.
4.Lightweight and Easy to Install: Geocells are lightweight and easy to handle, reducing transportation costs and labor during installation.
5.Environmentally Friendly: Geocells are made of recyclable materials, making them a sustainable solution for soil stabilization.
1. Geocell price material type
Geocells are usually made of plastic materials such as polypropylene (PP) and polyester (PET). Different raw materials will directly affect the price. For example, polypropylene (PP) geocells are usually cheaper, while high-strength polyester (PET) geocells are more expensive.
2. Geocell price specifications and thickness
The specifications, mesh size, thickness, etc. of geocells all affect the price. Large-scale, high-strength, and high-density geocells are usually more expensive.
3. Geocell price and purchase volume
Bulk purchases can usually get lower unit prices, so the purchase volume is an important factor affecting the price. The larger the single purchase volume, the more favorable the unit price is usually.
4. Geocell price manufacturer and brand
The prices of geocells from different brands and manufacturers vary greatly. Some well-known brands may provide higher quality and better after-sales service, but the prices are also relatively high. Some small manufacturers may provide geocells at a lower price, but the quality and service are less guaranteed.
5. Geocell price, transportation and delivery
Geocells are usually larger and heavier, so transportation costs may also affect the final price. Transportation costs may vary in different regions.
Shandong groadgeo Engineering Materials Co., Ltd. is a company dedicated to the research and development, production, and sales of geotechnical materials and related engineering products, committed to providing high-performance engineering materials for industries such as roads, bridges, railways, water conservancy, and environmental protection. Main products; Geotextile, geomembrane, geogrid, geonet, geotextile bag, composite geomembrane, etc. The product is widely used in infrastructure construction, environmental protection, mining, landfill, road reinforcement and other fields. With advanced production technology and rich industry experience, the company has become one of the important suppliers in the geotechnical materials industry.
1.Road foundation reinforcement: In the construction of infrastructure such as roads, airport runways, and railways, geotechnical materials are used to enhance the bearing capacity of the foundation and prevent uneven settlement. For example, geotextiles, geogrids, and geomembranes can be used to separate different soil layers, enhance soil stability, and reinforce foundations.
2.Dams, revetments, and reservoirs: Geotechnical materials are commonly used in hydraulic engineering for anti-seepage, drainage, and reinforcement purposes. Geomembranes, geotextiles, and geogrids are widely used for anti-seepage treatment of dams, lake and reservoir bottoms and sides, to prevent water infiltration and ensure structural stability.
3.Anti seepage and isolation of landfills: Geomembranes and geotextiles play a role in preventing seepage, isolation, and pollution at the bottom and sides of landfills. Geomembranes can effectively prevent the pollution of groundwater sources by leachate from garbage, while geotextiles provide filtration to prevent the infiltration of small particles.
Slope protection: In mountainous and sloping areas, geotechnical materials such as geotextiles, geonets, and geogrids are commonly used to prevent soil erosion. They effectively control soil erosion by stabilizing soil structure, reducing water flow erosion, and promoting vegetation restoration.
1.Geogrid: Used for reinforcing the shore to prevent wave erosion of soil and enhance the stability of protective walls.
2.Geotextile: Used to prevent soil erosion and help fix vegetation. It can improve soil stability, promote plant growth, and reduce soil erosion.
3.Geomembrane: As an anti-seepage material, it prevents seawater from invading the soil layer behind it, ensuring long-term effectiveness of protective measures.
4.Geonet: Used to enhance protective structures, especially in the reinforcement of vertical walls and slopes.
The importance of geotechnical materials in various complex environments and projects, whether it is infrastructure construction, water conservancy engineering, environmental protection, or soil reinforcement and waterproofing, geotechnical materials can play a key role. They help solve engineering problems and ensure the successful implementation of projects by improving soil properties, enhancing structural stability, protecting the environment, and improving durability.
Shandong Groadgeo Engineering Materials Co., Ltd., with its strong technical strength, advanced production equipment, and rich industry experience, has become one of the leading enterprises in the geotechnical materials industry at home and abroad. Through continuous innovation and product optimization, Lutai Company not only occupies an important position in the Chinese market, but also establishes a good brand image in the international market.
1.Advanced production equipment: The company has introduced internationally advanced production equipment and adopted high-tech production processes to ensure that every product meets international quality standards.
2.Independent research and development capability: Lutai Company has a technically strong R&D team that continuously develops new products and innovates technology, striving to maintain technological leadership in the field of geotechnical materials.
3.Quality control: The company has a sound quality management system, and all products have passed ISO9001 quality management system certification to ensure stable and reliable quality of each batch of products.
